DC Movable II

Compact, Powerful, Flexible.

Smart. Powerful. Highly Reliable.

Transportable, stand-alone, plug & play DC fast charger on wheels. DC fast-chargers can be equipped with CCS1, CHAdeMO and NACS connectors.

MOVABLE DC COMPACT CHARGERS IDEAL FOR

Dealerships
Fleets
Repair Shops
Play Button

General Characteristics

Output Power
50Kw
Connectivity
WiFi, 4G, Ethernet
Peak Efficiency
≥94%
Enclosure rating
IP54/IK10
Operating temperature range
-30℃ to 55℃(-22℉ to 131℉)
Storage temperature range
-40℃ to 70℃ (-40℉ to 158℉
Mounting
Movable Wheels
Dimension (H x W x D)
1218 x 638 x 670 mm
(47.9 x 25.1 x 26 inch)

Multiple Connectors
Dual CCS or CCS + CHAdeMO​

Credit card reader
RFID reader
App-based payment

Certifications and Standards

Safety standards
IEC 61851-1, IEC 61851-23, IEC 61851-21-2,
IEC  62196-3, IEC 60309, UL 2202,
UL 2231-1, UL, 231-2CSA Std. c22.2
No. 281.2, CSA Std. c22.2 No. 107.1,
C22.2 No. 182.1-, EMC Class A FCC Part 15
Warranty
Warranty extension possible

AC Input

Earthing system
3P, PE (No neutral)
Input voltage
3-phase 480V AC +6%~-10%
Input frequency
50...60Hz
Power factor
≥0.92
Download Technical Document
